LOCKWOOD 3774VTH HOLD BACK ANTI VANDAL LOCK WITH TURN SATIN STAINLESS

LOCKWOOD 3774VTH HOLD BACK ANTI VANDAL LOCK WITH TURN SATIN STAINLESS

LOCKWOOD 3774VTH HOLD BACK ANTI VANDAL LOCK WITH TURN (SATIN STAINLESS)

Benefits
• Easy red/green function setting
• All lock settings are made from under the faceplate allowing for simple in-door configuration
• Standard primary locks include anti-lockout and holdback capabilities
• Improved cylinder functions including lock/unlock and retract latch as standard
• Through-fixing of rose furniture turnknobs and escutcheons
• Reduced range of cylinder cams and turn adaptors relative to other commonly
available commercial cylinder mortice loc

Features and Specifications
The Australian designed and made Selector® 3770 Series Cylinder Mortice
Locks are made from quality materials to meet high durability and strength requirements.

Case and Faceplates
• High purity zinc alloy material cases with stainless steel chassis plates. Stainless steel faceplates provided as standard.

Latch Bolts
• Latch bolts are made with stainless steel,15mm in size
• Deadlatching is achieved by an auxiliary stainless steel latch bolt
• Reversible for both left and right hand doors,opening in or opening out whilst lock is
in door
• Electric Strike compatibility
• Separate auxiliary bolt moves into lock case simultaneously with latch bolt
• Radius bolt provides greater deadlatch throw and smoother closing action

Fire Rating
All Selector® 3770 Series Mortice Locks have been successfully tested up to 4 hours
(depending on type of doorset) on fire door assemblies in accordance with Australian
Standard AS 1905.1-2005, Part 1: Fire Resistant Doorsets.

If you require assistance with your selection please contact us either by email or phone.

Fire.pngSupplied With Fixings

Sets Come Complete With All Items Required For Standard Operation.
PLEASE NOTE THIS ITEM INCLUDES LOCK BODY & (CYLINDER IF  REQUIRED) ONLY DOES NOT INCLUDE HANDLES

Backset - 60mm Standard
Backsets Available - 60mm - 89mm - 127mm Price On Application
Door Thickness Standard - 32-50mm


External Function - Opened by handle when unlocked. Key locks or unlocks both handles and retracts bolt after unlocking lock.
Internal Function - Opened by handle when unlocked. Turnknob locks or unlocks both handles

Fire.pngFire Rated - Four hour fire rating (refer to door manufacturer)

Available Finishes - Antique Copper - Aged Brass - Architectural Unlacquered Bronze - Architectural Bronze - Chrome Plate - Matt Black - Oil Rubbed Bronze - Polished Brass

(ADD FINISH KIT AND CYLINDER TO SATIN STAINLESS LOCK)

FOR RELATED PRODUCTS REFER BOTTOM OF PAGE

CLICK TO VIEW ALL STAINLESS STEEL PRODUCTS

Downloadable Files

Downloads

Code Supplier Part Number Image Name Unit Function Product Options Finish Door Type Depth Backset Door Thickness Returns Policy Privacy Policy Price Quantity
LW3774VTH SS 3774VTH LOCKWOOD 3774VTH HOLD BACK ANTI VANDAL LOCK WITH TURN SATIN STAINLESS
  • Unit:
    Kitset
  • Function:
    Office Lock (Key & Turn)
  • Product Options:
    Both Handles Locked Or Unlocked
  • Finish:
    Stainless (Satin 304)
  • Door Type:
    Timber Doors Non Egress
  • Depth:
    88mm
  • Backset:
    60mm
  • Door Thickness:
    32mm-50mm Doors
  • Returns Policy:
    20 Percent Surcharge
 Kitset Office Lock (Key & Turn) Both Handles Locked Or Unlocked Stainless (Satin 304) Timber Doors Non Egress 88mm 60mm 32mm-50mm Doors 20 Percent Surcharge 20 Percent Surcharge
$229.12 (exc GST)
