YALE SUMMIT (L1) PALLADIUM 30MM 2PT 24MM LOCK KITSET MATT BLACK

YALE SUMMIT (L1) PALLADIUM 30MM 2PT 24MM LOCK KITSET MATT BLACK

YALE SUMMIT (L1) 30MM 24MM 2 POINT LOCKING KITSETS (MATT BLACK)

As part of the Palladium series, the Acacia handle represents the highest standard of residential and semi-commercial door hardware. With superior performance and elegant styling the Acacia handle complements a wide range of modern joinery. The handles have been created specifically for external doors with a long plate design which complements aluminium joinery. By having a range of levers, also available on other escutcheons within ASSA ABLOY’s product range, customers can achieve a consistent look throughout the home by matching their internal and external door hardware. The Induro mortice lock offers a new and improved locking system with enhanced furniture options available. When deadlocked, the Induro 2-Point provides increased security with two points of locking. Made specifically for the New Zealand environment, this is an ideal locking solution. Designed to be used in conjunction with the Verona and Palladium furniture ranges. Features Features 2 points of locking from the latch and deadbolt The handing of the lockset is adjusted by reversing the orientation of the latch bolt 85mm pitch Stainless steel forend plate Adjustable latch projection Latch wear insert included Achieves Australian Standards AS4145: 2008 (Part 2) Security Level S7 and Durability Level D7 The Acacia furniture mechanism incorporates a lever handle torsion spring and shuttle mechanism which provides a positive feel and increased product life Includes 92mm x 7.6mm square stepped spindle 30/30 Euro double cylinder cylinder When used with the correct strike the lock generates optimum seal compression to provide improved water and air seal performance, especially for large panel doors
	Supplied With Fixings
	Sets Come Complete With All Items Required For Standard Operation. Lock strike plate not included with lock but can be purchased separately if required
	Backset - 30mm Bolt Throw - 24mm Door Thickness - 35mm-41mm Cylinder Length - 60mm - Double Keyed & Key & Turn Cylinder Length - 30mm - Key Only Or Turn Only Pitch (Cylinder Spacing - 85mm
	Key or turn locks or unlocks both handles and latchbolt
	Available Finishes - Matt Black - Popular Powdercoat - Satin FOR RELATED PRODUCTS REFER BOTTOM OF PAGE CLICK TO VIEW ALL BLACK PRODUCTS

Downloadable Files

Downloads

Code	Supplier Part Number	Image	Name	Unit	Function	Product Features	Finish	Backset	Bolt Throw	Returns Policy	Privacy Policy	Price	Quantity
YLPL82601L1B	PL82601L1B		YALE PL82601L1B PALLADIUM 30MM 2PT 24MM DOUBLE KEY LOCKSET MATT BLACK Unit: Set Function: Lock Kit With Double Key Cylinder Product Features: 2 Point Locking Locks Finish: Black Backset: 30mm Bolt Throw: 24mm Returns Policy: Non Returnable Item	Set	Lock Kit With Double Key Cylinder	2 Point Locking Locks	Black	30mm	24mm	Non Returnable Item	Non Returnable Item	Retail: $195.73 (exc GST) Special: $174.20 (exc GST)	Quantity:
YLPL82602L1B	PL82602L1B		YALE PL82602L1B PALLADIUM 30MM 2PT 24MM KEY-TURN LOCKSET MATT BLACK Unit: Set Function: Lock Kit With Key & Turn Cylinder Product Features: 2 Point Locking Locks Finish: Black Backset: 30mm Bolt Throw: 24mm Returns Policy: Non Returnable Item	Set	Lock Kit With Key & Turn Cylinder	2 Point Locking Locks	Black	30mm	24mm	Non Returnable Item	Non Returnable Item	Retail: $195.73 (exc GST) Special: $174.20 (exc GST)	Quantity:
YLPL82604L1B	PL82604L1B		YALE PL82604L1B PALLADIUM 30MM 2PT 24MM INT-KEY LOCKSET MATT BLACK Unit: Set Function: Lock Kit With Int Key Cylinder Product Features: 2 Point Locking Locks Finish: Black Backset: 30mm Bolt Throw: 24mm Returns Policy: Non Returnable Item	Set	Lock Kit With Int Key Cylinder	2 Point Locking Locks	Black	30mm	24mm	Non Returnable Item	Non Returnable Item	Retail: $195.73 (exc GST) Special: $174.20 (exc GST)	Quantity:
