RAVEN RP114 DOOR BOTTOM SEALS

RAVEN RP114 DOOR BOTTOM SEALS
Smoke.pngAmbient (cold) Smoke
Smoke.png Hot Smoke Proof
Sound.pngNoise - Acoustic
Function.pngLight Proof
Messure Volume.pngEnergy,Draught and Dust
Insect.pngInsects and Vermin
Fire.pngFire (approved) New Zealand NZS 4520 and NZ Building Code Compliance Document C.

RAVEN RP114 DOOR BOTTOM SEAL

PRODUCT DESCRIPTION

Available Lengths - 915mm - 1220mm

RP114 is a door bottom intumescent fire and hot smoke seal that is designed to salvage non-compliant fire doors where clearances exceed 10mm under fire doors as per AS/NZS 1905.1.

The simple retrofit design avoids costly door replacement and the need to remove the door during installation.
RP114 is approved for use on leading proprietary fire doors.

Note: RP114 should just clear the floor during door opening and closing. To avoid the seal fouling on uneven or sloping surfaces, the finned gasket portion should engage an approved Raven threshold plate. This will enhance the other icon sealing functions.

Location: Bottom of fire and smoke doors.

Min/Max Gap: 14mm to 20mm (without threshold plate).

Finish: Satin clear (silver) or bronze anodised aluminium (15 µm).

Fixing: Screw fix. Zinc plated, cross recess head S.T. screws supplied.

Seal: Intumescent infill, grey flexible PVC (SE) cover strip and finned gasket.



Downloadable Files

Downloads

Code Supplier Part Number Image Name Unit Application Function Finish Overall Length Mounting Returns Policy Privacy Policy Price Quantity
RP114 915 CA OEM114C915 RAVEN RP114 DOOR BOTTOM FIRE SMOKE SEAL 915 CLEAR ANODISED
  • Unit:
    Each
  • Application:
    Weather,Energy Draughts And Dust,Light,Insects And Vermin,Cold Smoke,Fire And Hot Smoke,Fire Approved,Acoustic
  • Function:
    Door Bottom Seals
  • Finish:
    Clear Anodised
  • Overall Length:
    .915 Metre
  • Mounting:
    Screw Fix
  • Returns Policy:
    Non Returnable Item
 Each Weather,Energy Draughts And Dust,Light,Insects And Vermin,Cold Smoke,Fire And Hot Smoke,Fire Approved,Acoustic Door Bottom Seals Clear Anodised .915 Metre Screw Fix Non Returnable Item Non Returnable Item
$98.09 (exc GST)
Unavailable for Online Purchase, Contact Us
RP114 1220 CA OEM114C1220 RAVEN RP114 DOOR BOTTOM FIRE SMOKE SEAL 1220 CLEAR ANODISED
  • Unit:
    Each
  • Application:
    Weather,Energy Draughts And Dust,Light,Insects And Vermin,Cold Smoke,Fire And Hot Smoke,Fire Approved,Acoustic
  • Function:
    Door Bottom Seals
  • Finish:
    Clear Anodised
  • Overall Length:
    1.22 Metres
  • Mounting:
    Screw Fix
  • Returns Policy:
    Non Returnable Item
 Each Weather,Energy Draughts And Dust,Light,Insects And Vermin,Cold Smoke,Fire And Hot Smoke,Fire Approved,Acoustic Door Bottom Seals Clear Anodised 1.22 Metres Screw Fix Non Returnable Item Non Returnable Item
$116.62 (exc GST)
Unavailable for Online Purchase, Contact Us
